TS-G6820S

TS-G6820S

$60.00

Find out if this product fits your vehicle

Select quantity

6" x 8" - 2-way, 250 W Max Power, IMPP™ cone, 30mm Tweeter - Coaxial Speakers (pair)

250 W Max Power (40 W Nominal)

6" x 8" Injected Molded Polypropylene (IMPP) Composite Cone Woofer

Patented Pioneer P.F.S.S Spider

30mm Balanced Dome Tweeter

Overview
Specs
Knowledgebase
Manuals/Warranty

Our TS-G6820S speakers are excellent choices to replace a bad set of factory 6" x 8" speakers. Their two-way design handles 250 W max. power (40 W RMS) and features Pioneer’s extremely strong and lightweight Injected Molded Polypropylene IMPP™ with MICA composite cone woofer for improved sensitivity and reduced distortion. You don't get just basic, run-of-the-mill features either. The conex damper delivers higher power handling and deeper bass, and the 30mm Balanced dome tweeter reproduces highs with great performance and musicality. These speakers are designed with a shallow mounting depth for easy installation and custom-fit baskets for select Ford and Mazda vehicles.

P.F.S.S. spider

Progressive Flex Suspension System supports the voice coil effectively by dampening the large cone vibration and enhancing linearity of sound reproduction. Its soft part makes movement smooth and reproduces clear sound and at excessive input, while its hard part controls excessive vibration and prevents movement error.

Installation and sound to suite any car

These speakers are excellent choices to replace a bad set of factory speakers. Their two-way design features Pioneer’s extremely strong and lightweight Injected Molded Polypropylene™ (IMPP) with MICA composite cone woofer for improved sensitivity and reduced distortion. You don't get just basic, run-of-the-mill features either. The conex damper delivers higher power handling and deeper bass, and the Balanced dome tweeter reproduces highs with great performance and musicality. These speakers are designed with a shallow mounting depth for easy installation and custom-fit baskets for select Ford and Mazda vehicles.

FEATURES
Cut Out dimensions 7-1/2 x 5-1/4	Mounting Depth 2-1/2 - Tweeter
Tweeter 30mm

FEATURES
Cut Out dimensions 7-1/2 x 5-1/4
Mounting Depth 2-1/2 - Tweeter
Tweeter 30mm

MATERIALS
Cone Material IMPP - with MICA	Surround Material Rubber Coated Cloth
Basket Material Metal	Magnet Weight 5.5 oz
Voice Coil wire Copper	Surround Type Rolled
Magnet Material Ferrite	Damper Poly cotton

MATERIALS
Cone Material IMPP - with MICA
Surround Material Rubber Coated Cloth
Basket Material Metal
Magnet Weight 5.5 oz
Voice Coil wire Copper
Surround Type Rolled
Magnet Material Ferrite
Damper Poly cotton

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 40W	Crossover Frequency NA
Frequency Response 72 Hz to 14 kHz	Maximum Peak Power Handling - Watts 250W
Nominal Impedance - Ohm 4-Ohm	Sensitivity (1W/1m) 92 dB
System-Type Coaxial 2-way, Balance Dome - Tweeter

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 40W
Crossover Frequency NA
Frequency Response 72 Hz to 14 kHz
Maximum Peak Power Handling - Watts 250W
Nominal Impedance - Ohm 4-Ohm
Sensitivity (1W/1m) 92 dB
System-Type Coaxial 2-way, Balance Dome - Tweeter
