QuickSwipe Access
Minimize distractions with the new direct access buttons located on the left side of the unit. Perform quick interactions like making calls, initiate voice actions, go to app screens, and return to the main menu in 1-click instead of 2 to 3 times more interactions.
ShortCut Keys
Change the layout of your main menu and make it the way you like and put aside the things you don’t need. Pioneer’s new NEX receivers are offering a host of options for AV sources and other car AV features. But it is not because this offer is large that it must be heavy on visuals and complicated for the access.
Wireless connectivity
This Pioneer Receiver supports a cable free connection between your smartphone using Wi-Fi wireless connectivity and is compatible with Android Auto, Apple CarPlay and Wi-Fi certified Miracast. Its your choice, wireless or wired. Additional fees may apply.
Android Auto
A simpler, safer way to use your phone in the car. Get all your favorite maps, media, and messaging apps on your car display. To use Android Auto, you need a compatible Android smartphone with an active data plan.
Apple CarPlay
A smarter, safer way to use your iPhone while you drive. You can get directions, make calls, send, and receive messages, and enjoy your favorite music all on the built-in display.
iDataLink Maestro (RR & RR2)
iDatalink Maestro RR and RR2 (both sold separately), preserves factory features such as climate control, performance gauges and vehicle information such as tire pressure and diagnostics. Features vary by vehicle.
Back up camera input (1-camera)
Back up safely in any crowded parking area. Install a rear-view camera to use the receiver’s built-in parking guides for easy parking, with adjustable parking lines and full screen image for ease of use.
HD Radio
This Pioneer Receiver has a built-in HD Radio tuner, broadcasting in clear digital quality. Many stations offer extra local FM channels to enjoy more music, news, and sports – all 100% subscription FREE! Your FM and AM stations now have crystal-clear reception with no audio distortion.
HEAD UNIT AUDIO | |
---|---|
Advanced Sound Retriever
No
|
Audio Bass Boost
Yes
|
Auto EQ (CD-MC20 Microphone sold separately)
No
|
Automatic Level Control
No
|
Auto Sound Levelizer (ASL)
No
|
Balance
Yes
|
Bass & Treble
No
|
Built-in Amplifier
MOSFET 50 W x 4
|
Crossover Standard Mode
HPF/LPF
|
Customizable Graphic Equalizer
13 Band
|
DA Converter
24 Bit
|
Digital Signal Processor
Built In
|
Dynamic Bass Enhancer
No
|
Easy EQ (EEQ) Preset Equalizer
Yes
|
Fade
Yes
|
Listening Position Selector
Yes
|
Loudness
High/Mid/Low/Off
|
MIXTRAX®
No
|
Source Level Adjuster
No
|
Speaker Output
4-ch
|
Spectrum Analyzer
No
|
Subwoofer Control
Yes
|
HEAD UNIT AUDIO |
---|
Advanced Sound Retriever
No
|
Audio Bass Boost
Yes
|
Auto EQ (CD-MC20 Microphone sold separately)
No
|
Automatic Level Control
No
|
Auto Sound Levelizer (ASL)
No
|
Balance
Yes
|
Bass & Treble
No
|
Built-in Amplifier
MOSFET 50 W x 4
|
Crossover Standard Mode
HPF/LPF
|
Customizable Graphic Equalizer
13 Band
|
DA Converter
24 Bit
|
Digital Signal Processor
Built In
|
Dynamic Bass Enhancer
No
|
Easy EQ (EEQ) Preset Equalizer
Yes
|
Fade
Yes
|
Listening Position Selector
Yes
|
Loudness
High/Mid/Low/Off
|
MIXTRAX®
No
|
Source Level Adjuster
No
|
Speaker Output
4-ch
|
Spectrum Analyzer
No
|
Subwoofer Control
Yes
|
HEAD UNIT BLUETOOTH | |
---|---|
Built-in Bluetooth®
Yes
|
Hands-Free
Yes
|
AVRCP
1.6
|
Advanced Audio Distribution Profile (A2DP)
Yes
|
Secure Simple Pairing (SSP)
Yes
|
Serial Port Profile (SPP)
Yes
|
Dual Phone Connection
Yes
|
Sound Retriever Air
Mode 1/Mode 2/Off
|
Guest Mode
No
|
Hands Free Version
1.6
|
Microphone Included
Included
|
HEAD UNIT BLUETOOTH |
---|
Built-in Bluetooth®
Yes
|
Hands-Free
Yes
|
AVRCP
1.6
|
Advanced Audio Distribution Profile (A2DP)
Yes
|
Secure Simple Pairing (SSP)
Yes
|
Serial Port Profile (SPP)
Yes
|
Dual Phone Connection
Yes
|
Sound Retriever Air
Mode 1/Mode 2/Off
|
Guest Mode
No
|
Hands Free Version
1.6
|
Microphone Included
Included
|
HEAD UNIT DIGITAL MEDIA PLAYBACK | |
---|---|
Audio Playback via USB
WMA Audio Playback, MP3 Audio Playback, WAV Audio Playback (Hi-Res), AAC Audio Playback, FLAC Audio Playback (Hi-Res)
|
Audio Video Playback via USB
.3gp, .avi, .divx, .f4V, H.263, H.264, .m4v, .mkv, .mov, .mp4, .mpg/mpeg, .wmv/.asf
|
Image Display Via USB
BMP, JPEG, PNG
|
HEAD UNIT DIGITAL MEDIA PLAYBACK |
---|
Audio Playback via USB
WMA Audio Playback, MP3 Audio Playback, WAV Audio Playback (Hi-Res), AAC Audio Playback, FLAC Audio Playback (Hi-Res)
|
Audio Video Playback via USB
.3gp, .avi, .divx, .f4V, H.263, H.264, .m4v, .mkv, .mov, .mp4, .mpg/mpeg, .wmv/.asf
|
Image Display Via USB
BMP, JPEG, PNG
|
HEAD UNIT DISPLAY | |
---|---|
Anti Glare/Reflection
No
|
Back Light
LED
|
Brightness Control
Yes
|
Device Display
No
|
Device (Non-DIN/Modular Unit)
2-DIN
|
Dimmer
Automatic with vehicle illumination, Manual
|
Display Off Mode
Yes
|
Home Screen Customization
Yes
|
Monitor Mechanism
Fixed
|
Resolution
WVGA (800 x 480)
|
Screen Size/Aspect Ratio
6.8/16:9
|
Touch Screen
Capacitive
|
HEAD UNIT DISPLAY |
---|
Anti Glare/Reflection
No
|
Back Light
LED
|
Brightness Control
Yes
|
Device Display
No
|
Device (Non-DIN/Modular Unit)
2-DIN
|
Dimmer
Automatic with vehicle illumination, Manual
|
Display Off Mode
Yes
|
Home Screen Customization
Yes
|
Monitor Mechanism
Fixed
|
Resolution
WVGA (800 x 480)
|
Screen Size/Aspect Ratio
6.8/16:9
|
Touch Screen
Capacitive
|
HEAD UNIT EXPANDABILITY | |
---|---|
Audio Video Inputs
Input 1 - Backup Camera Dedicated, Audio/Video AUX (Minijack)
|
Dual Zone Rear-Seat Entertainment
No
|
OEM Integration
iDatalink Maestro RR, iDatalink Maestro RR2
|
OTA Update Compatabile
Yes
|
Parking Assist Lines
Yes
|
RCA-Video-Output
No
|
SD/SDHC Memory Card Slot
No
|
USB
Single Rear Type-A (5V, 1-1/2 A)
|
USB Direct Control for iPhone®
5s and newer
|
HEAD UNIT EXPANDABILITY |
---|
Audio Video Inputs
Input 1 - Backup Camera Dedicated, Audio/Video AUX (Minijack)
|
Dual Zone Rear-Seat Entertainment
No
|
OEM Integration
iDatalink Maestro RR, iDatalink Maestro RR2
|
OTA Update Compatabile
Yes
|
Parking Assist Lines
Yes
|
RCA-Video-Output
No
|
SD/SDHC Memory Card Slot
No
|
USB
Single Rear Type-A (5V, 1-1/2 A)
|
USB Direct Control for iPhone®
5s and newer
|
HEAD UNIT GENERAL | |
---|---|
Detachable Face Security
Fixed
|
Flap Face
No
|
Multi-Language Display
English, French, Spanish Portuguese, Chinese (Simplified)
|
Music Browser
USB
|
Remote Control
No
|
Rotary Volume Control
No
|
Smartphone Cradle
No
|
Steering Wheel Control Ready (Adapter Sold Separately)
Yes
|
HEAD UNIT GENERAL |
---|
Detachable Face Security
Fixed
|
Flap Face
No
|
Multi-Language Display
English, French, Spanish Portuguese, Chinese (Simplified)
|
Music Browser
USB
|
Remote Control
No
|
Rotary Volume Control
No
|
Smartphone Cradle
No
|
Steering Wheel Control Ready (Adapter Sold Separately)
Yes
|
HEAD UNIT INTEGRATION | |
---|---|
Amazon Alexa
Paired with Pioneer Vozsis
|
Android Auto™
Wireless Connection or Wired USB Connection
|
Apple® CarPlay
Wireless Connection or Wired USB Connection
|
AppRadio Mode+
No
|
CarAVassist
No
|
Gracenote Sports
No
|
Mirroring
USB-Android Phone Only
|
Mobile Operating System
Android - Wired/WirelessApple iOS - Wired/Wireless
|
Music Playback (MTP)
No
|
Pandora®
With Apple CarPlay or Android Auto
|
Pioneer App Compatibility
Vozsis Android, Vozsis iPhone
|
Siri® Eyes Free (VR) (Internet Required)
iPhone Only
|
Spotify
With Apple CarPlay or Android Auto
|
Voice Control
Yes
|
Weblink
Version 2.0
|
HEAD UNIT INTEGRATION |
---|
Amazon Alexa
Paired with Pioneer Vozsis
|
Android Auto™
Wireless Connection or Wired USB Connection
|
Apple® CarPlay
Wireless Connection or Wired USB Connection
|
AppRadio Mode+
No
|
CarAVassist
No
|
Gracenote Sports
No
|
Mirroring
USB-Android Phone Only
|
Mobile Operating System
Android - Wired/WirelessApple iOS - Wired/Wireless
|
Music Playback (MTP)
No
|
Pandora®
With Apple CarPlay or Android Auto
|
Pioneer App Compatibility
Vozsis Android, Vozsis iPhone
|
Siri® Eyes Free (VR) (Internet Required)
iPhone Only
|
Spotify
With Apple CarPlay or Android Auto
|
Voice Control
Yes
|
Weblink
Version 2.0
|
HEAD UNIT TUNER | |
---|---|
Best Station Memory
Yes
|
HD Radio™
Built In
|
Hybrid Radio
No
|
Local Seek tuning
Yes
|
Presets
18 FM 12 AM
|
PS (Preset Scan)
No
|
RDS
Yes
|
SiriusXM-Ready™ (Tuner Sold Separately)
Yes
|
Supertuner® IIID
No
|
HEAD UNIT TUNER |
---|
Best Station Memory
Yes
|
HD Radio™
Built In
|
Hybrid Radio
No
|
Local Seek tuning
Yes
|
Presets
18 FM 12 AM
|
PS (Preset Scan)
No
|
RDS
Yes
|
SiriusXM-Ready™ (Tuner Sold Separately)
Yes
|
Supertuner® IIID
No
|
PRODUCT PERFORMANCE | |
---|---|
Continuous Power Output
22 W x 4-Channel
|
Load Impedence Allowance
4 Ohm (4 Ohm to 8 Ohm Allowable)
|
RCA Preamp Outputs
6-ch
|
RCA Preout Voltage
4V
|
RMS Power Output (CTA-2006)
14 W RMS x 4-ch 4 ohm
|
Signal to Noise
No
|
PRODUCT PERFORMANCE |
---|
Continuous Power Output
22 W x 4-Channel
|
Load Impedence Allowance
4 Ohm (4 Ohm to 8 Ohm Allowable)
|
RCA Preamp Outputs
6-ch
|
RCA Preout Voltage
4V
|
RMS Power Output (CTA-2006)
14 W RMS x 4-ch 4 ohm
|
Signal to Noise
No
|
