Name: TS-F1634R
Brand: Pioneer Electronics (USA) Inc.
SKU: TS-F1634R
Price: 25.0 USD
Availability: InStock

TS-F1634R

$25.00

Find out if this product fits your vehicle

Select quantity

6-1/4" - 2-Way, 200 W Max Power, and 30mm Tweeter - Coaxial Speakers (pair)

200 Watts Max Power (25 Watts Nominal)

30mm Tweeter

Water-resistant Injection-molded polypropylene Cone

Heat-resistant Voice Coil

Overview
Specs
Knowledgebase
Manuals/Warranty

Pioneer TS-F1634R 2-Way Coaxial Car Audio Speakers Full Range 6.5" Round Speakers 200W Max Enhanced Bass Response Easy Installation Black Car Speakers.

Power Handling

Delivering 200W (25W nominal) with 4-ohm impedance, these speakers combine style and high-quality sound for a dynamic audio experience.

2-Way Coaxial Design

The innovative coaxial setup integrates a woofer and tweeter for balanced, immersive sound, ensuring a full range of frequencies during your drive.

Sensitivity

With an 88dB sensitivity rating, enjoy distortion-free music at higher volumes, ensuring a clear and loud audio experience with lower power inputs.

6.5in Standard Sizing

Designed with a standard 6.5-inch diameter, these speakers seamlessly integrate into most car interiors, offering versatility without compromising performance.

MATERIALS
Cone Material Injected Molded Polypropylene -IMPP Composite

MATERIALS
Cone Material Injected Molded Polypropylene -IMPP Composite

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 200 watts	Frequency Response 31 Hz to 16 kHz (-20 dB)
Maximum Peak Power Handling - Watts 25 watts	Sensitivity (1W/1m) 88 dB
System-Type Coaxial 2-Way

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 200 watts
Frequency Response 31 Hz to 16 kHz (-20 dB)
Maximum Peak Power Handling - Watts 25 watts
Sensitivity (1W/1m) 88 dB
System-Type Coaxial 2-Way

Instruction Manual ()
Product Warranty ()
