Name: TS-G1320S
Brand: Pioneer Electronics (USA) Inc.
SKU: TS-G1320S
Price: 60.0 USD
Availability: InStock

TS-G1320S

$60.00

Find out if this product fits your vehicle

Select quantity

5.25” - 2-way, 250 W Max Power, Mica-reinforced IMPP™ cone, 1.2" (30 mm) PET tweeter - Coaxial Speakers (pair)

250 Watts Max. Power / 35 Watts Nominal Power

5.25” Mica reinforced IMPP™ cone

30 mm (PET) hard dome tweeter

Frequency range: 33 Hz to 24 kHz

Speaker Impedance: 4 ohms

Speaker Efficiency: 88 dB (1W/1M)

Patented Pioneer PFSS Spider

Overview
Specs
Knowledgebase
Manuals/Warranty

The TS-G1320S 5-1/4" two-way speakers with 250 W max power (35 W nominal) feature Pioneer's extremely strong and lightweight Injected Molded Polypropylene (IMPP™) cone for improved sensitivity and reduced distortion. The Conex damper delivers higher power handling and deeper bass, while the 25 mm balanced dome tweeter reproduces highs with great performance and musicality. These speakers are designed with a shallow mounting depth for easy installation in a wide variety of vehicles.

Affordable & Reliable OEM Speaker Replacement

These speakers are excellent choices for replacing a bad set of factory speakers. Their two-way design features Pioneer's extremely strong and lightweight Injected Molded Polypropylene (IMPP™) with a MICA composite cone woofer for improved sensitivity and reduced distortion. You don't just get basic, run-of-the-mill features either. The Conex damper delivers higher power handling and deeper bass, while the balanced dome tweeter reproduces highs with great performance and musicality. These speakers are designed with a shallow mounting depth for easy installation.

Mica reinforced IMPP™ cone

An extremely rigid yet lightweight cone is essential to avoid cone failure and distortion under high power. Pioneer's IMPP™ composite cones meet this need perfectly. To further improve this rigidity-to-weight ratio, Pioneer uses an advanced process that integrates different materials, such as mica, which resonate at different frequencies, creating a perfectly balanced cone across the entire bandwidth.

PET hard dome tweeter

The stable electrical and mechanical properties over a wide frequency range, as well as the strength-to-weight ratio of PET (Polyethylene Terephthalate), make it perfect for the high-frequency vibrations of the dome. We have also carefully designed the tweeter with a front diffuser to help maintain a perfect audio balance during the transition from on-axis to off-axis listening. This allows for a more balanced sound source between the different audio points in the car.

Pioneer exclusive PFSS spider

The Progressive Flex Suspension System (PFSS) effectively supports the voice coil by damping cone vibrations and improving the linearity of sound reproduction. Its soft part ensures smooth movement and clear sound even under high power, while its firmer part controls excessive vibrations and prevents unwanted movements that cause distortion. The goal is simple: to provide all the details of your music while maintaining control during the large excursions generated by the bass.

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 35W	Crossover Frequency NA
Frequency Response 33 Hz to 24 kHz	Maximum Peak Power Handling - Watts 250W
Nominal Impedance - Ohm 4-Ohm	Sensitivity (1W/1m) 88 dB
System-Type Coaxial 2-way,Balance Dome - Tweeter

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 35W
Crossover Frequency NA
Frequency Response 33 Hz to 24 kHz
Maximum Peak Power Handling - Watts 250W
Nominal Impedance - Ohm 4-Ohm
Sensitivity (1W/1m) 88 dB
System-Type Coaxial 2-way,Balance Dome - Tweeter

FEATURES
Cut Out dimensions 4-3/4"	Mounting Depth 1-3/4"
Tweeter 1-3/16"

FEATURES
Cut Out dimensions 4-3/4"
Mounting Depth 1-3/4"
Tweeter 1-3/16"

MATERIALS
Basket Material Metal	Cone Material IMPP - with MICA
Damper Poly cotton	Diaphragm Material Polyethylene terephthalate (PET) - Tweeter
Magnet Material Ferrite	Magnet Weight 3.9 oz
Shorting Ring Material Copper	Surround Material Rubber Coated Cloth
Surround Type Rolled	Voice Coil Material Kapton
Voice Coil wire Copper	Wire Terminals Lug Type

MATERIALS
Basket Material Metal
Cone Material IMPP - with MICA
Damper Poly cotton
Diaphragm Material Polyethylene terephthalate (PET) - Tweeter
Magnet Material Ferrite
Magnet Weight 3.9 oz
Shorting Ring Material Copper
Surround Material Rubber Coated Cloth
Surround Type Rolled
Voice Coil Material Kapton
Voice Coil wire Copper
Wire Terminals Lug Type
