TS-Z65CH

TS-Z65CH

$300.00

Find out if this product fits your vehicle

Select quantity

6-1/2" 2-way, 330 W Max Power, Twaron Aramid + Cellulose Fiber Cone, 29mm Aluminum Alloy Dome Tweeter-Swivel Design, Hi-Res Audio Certified - Component Speakers (pair)

29mm Aluminum Alloy Dome Tweeter with Vertex Drive System

Twaron® Aramid Fiber + Cellulose Fiber Dual Layer Cone Construction

Oversized Magnet and Powerful Motor Assembly for Accurate Bass

Designed for Hi-Res Audio

Overview
Specs
Knowledgebase
Manuals/Warranty

The Z-Series TS-Z65CH 6-1/2" component speaker system makes the very best way to add smooth, open, sound quality to your car. Equipped to handle power up to 110 W RMS, Pioneer built the Z-Series to harness that wealth of information and reproduce music incredibly close to the original performance. To ensure a premium audio experience, the Z-Series TS-Z65CH uses Twaron, a lightweight, heat-resistant fiber that is exceptionally strong and stable to create a woofer cone that will confidently handle your music's midrange and lows without undesirable resonance. An oversized aluminum dome tweeter reproduces the most demanding tones, while maintaining accuracy in high-level playback. With a frequency range up to 96,000 Hz, enjoy authentic reproduction of your finest recordings, with all the overtones and harmonics making music real. Compact, quality external crossover networks bring out the best in each driver so that you experience a seamless sound performance. With these gold-trimmed Z-Series speakers installed in your doors, turn up your music with confidence and savor all the nuances you've been craving in the car.

Cone Construction - Dual

Twaron is a synthetic aramid fiber that is very strong, heat resistant and rigid when woven into a cloth material. Cellulose fibers are naturally self-damping and reduce unwanted resonance. The TS-Z65CH dual layer cone, constructed with both a Twaron layer and a cellulose layer, combines the strengths of both materials. The result is fast response and clear bass, with low coloration and distortion.

Hi-Res Audio1 Speaker

The quality of music recordings available to listeners has evolved. Hi-Res Audio recordings contain significantly more data compared to a standard CD recording and require a loudspeaker that is capable of smoothly reproducing frequencies of 40kHz or higher. The Z speakers are designed to deliver sound that’s clearer, sharper and more complex - reproducing music that is closer to the original performance.

Tweeter - Balanced Dome

The Z tweeter’s aluminum alloy diaphragm allows the tweeter to remain pistonic and linear at ultrasonic frequencies. The unique diaphragm shape, developed using HSDOM (Harmonized Synthetic Diaphragm Optimum Method) computer analysis, accurately controls differential vibration produced by the diaphragm and improves high frequency dispersion. Pioneer’s Vertex Drive System improves the mechanical coupling of the voice coil and the tweeter diaphragm, reducing distortion and coloration caused by low damping and increasing power handling.

CarSoundfit

Pioneer’s Car Sound Fit app is actually a car sound simulator for experiencing in-car sound with your own smartphone. Hear the difference between original car speakers and different Pioneer audio upgrades: convince yourself of the level of quality Pioneer can offer for your vehicle. For a virtual listening demonstration of these and many other Pioneer car speakers, download the free Pioneer CarSoundFit app.

FEATURES
CarSoundFit Yes	Cut Out dimensions 5-5/8
Mounting Depth 2-1/2 - Midrange,5/8 - Tweeter	Outer Diameter 2-3/8
Protrusion 1/2	Tweeter 29mm
Tweeter Mounting Hole Diameter 2

FEATURES
CarSoundFit Yes
Cut Out dimensions 5-5/8
Mounting Depth 2-1/2 - Midrange,5/8 - Tweeter
Outer Diameter 2-3/8
Protrusion 1/2
Tweeter 29mm
Tweeter Mounting Hole Diameter 2

MATERIALS
Basket Material Metal	Center Cap Material Twaron Aramid Fiber
Cone Material IMPP - Aramid Fiber and Carbon Fiber	Custom Fit Basket No
Damper Aramid Fiber	Diaphragm Material Aluminum Alloy - Tweeter
Magnet Material Ferrite - Speaker,Neodymium - Tweeter	Magnet Weight 15.2 oz - Speaker,0.2 oz - Tweeter
Shorting Ring Material Copper	Surround Material Butyl Rubber
Surround Type Rolled	Swivel Type Yes
Voice Coil Material Glass Imide	Voice Coil wire Copper
Wire Terminals Lug Type

MATERIALS
Basket Material Metal
Center Cap Material Twaron Aramid Fiber
Cone Material IMPP - Aramid Fiber and Carbon Fiber
Custom Fit Basket No
Damper Aramid Fiber
Diaphragm Material Aluminum Alloy - Tweeter
Magnet Material Ferrite - Speaker,Neodymium - Tweeter
Magnet Weight 15.2 oz - Speaker,0.2 oz - Tweeter
Shorting Ring Material Copper
Surround Material Butyl Rubber
Surround Type Rolled
Swivel Type Yes
Voice Coil Material Glass Imide
Voice Coil wire Copper
Wire Terminals Lug Type

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 110	Crossover Frequency 4500 Hz (Acoustic),1900 Hz (Electric)
Frequency Response 30 Hz to 96 kHz	Maximum Peak Power Handling - Watts 330
Nominal Impedance - Ohm 4-Ohm	Sensitivity (1W/1m) 85 dB ( 1.5dB)
System-Type Component 2-way,Dome - Tweeter

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 110
Crossover Frequency 4500 Hz (Acoustic),1900 Hz (Electric)
Frequency Response 30 Hz to 96 kHz
Maximum Peak Power Handling - Watts 330
Nominal Impedance - Ohm 4-Ohm
Sensitivity (1W/1m) 85 dB ( 1.5dB)
System-Type Component 2-way,Dome - Tweeter
