Easily Upgrade to High Performance
Pioneer’s A-series sound design purposely matches the subwoofer and full-range loudspeakers to provide seamless and smooth sound characteristics with dynamic, high impact bass that lets you hear and feel the music.
Direct Fit IEM Upgrade
This is a 2-way coaxial 2-3/4 speaker. It is carbon and mica reinforced woofer cone stands up to the harsh in-car environment while providing natural-sounding tonal qualities with an OPEN & SMOOTH transition to the polyetherimide Tweeter.
Easy Installation
This speaker is designed as a direct OEM speaker replacement in many vehicles including Toyota, Dodge, Chevrolet, Chrysler and more.
High Audio Quality Capacitor
The inline audio quality capacitor is designed as an 850 Hz HPF or High Pass Filter. An HPF allows only higher frequencies above 850 Hz to the speaker. This protects this speaker from high-power low-frequency damage.
Open & smooth
Pioneer’s OPEN & SMOOTH sound concept provides a seamless and smooth transition between the midrange and tweeter drivers and delivers uniform off-axis frequency response optimized for automotive applications where one or more speakers are often aimed away from the listeners’ ears.
Learn Which Speakers Fit Your Car
Listening to your music is a big part of enjoying your drive to the fullest. By replacing your factory 2-3/4 or 3-1/2” speakers with Pioneer’s 2-way coaxial speakers, you can recreate your music with better clarity and improved range of sound. Both TS-A709 and TS-A879 speakers are designed to allow easy OEM replacement in many vehicles including Toyota, Dodge, Chevrolet, Chrysler and more. Click here to visit our installation coverage guide to learn which speakers will fit your vehicle.
FEATURES | |
---|---|
CarSoundFit
No
|
Cut Out dimensions
3
|
Mounting Depth
1-3/8/34.9mm
|
Tweeter
25mm
|
FEATURES |
---|
CarSoundFit
No
|
Cut Out dimensions
3
|
Mounting Depth
1-3/8/34.9mm
|
Tweeter
25mm
|
MATERIALS | |
---|---|
Basket Material
Resin
|
Center Cap Material
NA
|
Cone Material
Carbon and Mica reinforced Injected Molded Polypropylene - IMPP
|
Cone Special Feature
NA
|
Custom Fit Basket
Yes
|
Damper
Aramid Fiber
|
Diaphragm Material
Polyetherimide (PEI) - Midrange
|
Drive Cone Material
No
|
Magnet Material
Ferrite - Woofer,Neodymium - Midrange
|
Magnet Weight
4.5 oz - Woofer,0.1 oz - Midrange
|
Shorting Ring
No
|
Shorting Ring Material
NA
|
Surround Material
Rubber
|
Surround Type
Rolled
|
Voice Coil Material
Glass Imide
|
Voice Coil Type
Single Voice Coil
|
Voice Coil wire
Copper
|
Wire Terminals
Lug Type
|
MATERIALS |
---|
Basket Material
Resin
|
Center Cap Material
NA
|
Cone Material
Carbon and Mica reinforced Injected Molded Polypropylene - IMPP
|
Cone Special Feature
NA
|
Custom Fit Basket
Yes
|
Damper
Aramid Fiber
|
Diaphragm Material
Polyetherimide (PEI) - Midrange
|
Drive Cone Material
No
|
Magnet Material
Ferrite - Woofer,Neodymium - Midrange
|
Magnet Weight
4.5 oz - Woofer,0.1 oz - Midrange
|
Shorting Ring
No
|
Shorting Ring Material
NA
|
Surround Material
Rubber
|
Surround Type
Rolled
|
Voice Coil Material
Glass Imide
|
Voice Coil Type
Single Voice Coil
|
Voice Coil wire
Copper
|
Wire Terminals
Lug Type
|
PRODUCT PERFORMANCE | |
---|---|
Continuous Power handling (RMS) - Watts
100
|
Crossover Frequency
6,200 Hz - Acoustic,4,800 Hz - Electric,850 Hz Inline crossover network
|
Frequency Response
52 Hz to 33 kHz,850 Hz to 33kHz - with inline packaged crossover network
|
Maximum Peak Power Handling - Watts
450 W with packaged crossover network
|
Nominal Impedance - Ohm
4-Ohm
|
Sensitivity (1W/1m)
85 dB
|
System-Type
Coaxial 2-way
|
PRODUCT PERFORMANCE |
---|
Continuous Power handling (RMS) - Watts
100
|
Crossover Frequency
6,200 Hz - Acoustic,4,800 Hz - Electric,850 Hz Inline crossover network
|
Frequency Response
52 Hz to 33 kHz,850 Hz to 33kHz - with inline packaged crossover network
|
Maximum Peak Power Handling - Watts
450 W with packaged crossover network
|
Nominal Impedance - Ohm
4-Ohm
|
Sensitivity (1W/1m)
85 dB
|
System-Type
Coaxial 2-way
|
