Name: GM-A4704
Brand: Pioneer Electronics (USA) Inc.
SKU: GM-A4704
Price: 120.0 USD
Availability: InStock

GM-A4704

$120.00

Find out if this product fits your vehicle

Select quantity

4-Channel - Class AB, 520w Max Power - Bridgeable Amplifier

520 Watts Max Power

Automatic signal sensing and Turn-On

Variable high pass filter

Speaker level inputs

Overview
Specs
Knowledgebase
Manuals/Warranty

The GM-A4704 4-channel amplifier will greatly improve the sound quality in your vehicle, so you'll find yourself looking forward to your time on the road. This amplifier will power your front and rear speakers with up to 65 watts RMS each, which is actually a large jump over the power supplied by a typical car radio. You'll hear much more of the little details in your music, especially when you turn your system up to overcome road noise.

Variable HPF

Variable HPF (High Pass Filter) allows for adjustable frequency between 40 Hz to 500 Hz* and greater car audio system flexibility according to subwoofer characteristics and personal listening preference.

Automatic Signal sensing and Turn-On

Pioneer amplifiers automatically select the proper input signal mode, either RCA or speaker level. When the receiver is turned on, the amplifier automatically turns on. When connected to an OEM receiver or a receiver without RCA output and utilizing speaker level output, the amp automatically senses the input mode and powers up in sync with the receiver. When connected to an OEM receiver or a receiver without RCA output using speaker wire the amplifier is turned on at the same time as the receiver. Pioneer's amplifiers automatically detect the input signal and select RCA level or speaker level.

Growing Power - Shrinking size

New Pioneer amps brilliantly integrate high-power performance superior to that of previous models in space-efficient sizes for flexibility of installation in various car cabins.

Technology of the GM Series

From dramatic distinction to intricate design, Pioneer's new GM-Series amplifiers are thrillers in every sense, pushing the limits of flexibility and functionality.

AMP FEATURES
Bridgable Yes	Class A/B
Grounding System Negative	Power Source 14.4V (10.8 V to 15.1 V allowable)
Protection Control system Yes	Terminal Type Screw
Unit Weight 4.4 lbs

AMP FEATURES
Bridgable Yes
Class A/B
Grounding System Negative
Power Source 14.4V (10.8 V to 15.1 V allowable)
Protection Control system Yes
Terminal Type Screw
Unit Weight 4.4 lbs

PRODUCT PERFORMANCE
Allowable Load Impedance 2 ohm to 8 ohm allowable	Avg Current Consumption (amps x #ch) 5.5 A x 4-Channel - 4 Ohm, 8.5 A x 2-Channel - 4 Ohm
Continuous-Power-Output 40 W x 4-Channel - 4 Ohm, 65 W x 4-Channel - 2 Ohm, 130 W x 2-Channel - 4 Ohm Bridged	Crossover Network Channel LPF - A/B Ch - 80 Hz, HPF - A Ch - 40 Hz to 500Hz, HPF - B Ch - 80Hz
Crossover Network Channel Slope -12db/oct (A/B CH)	Crossover Network Subwoofer Channel LPF - 80 Hz
Crossover Network Subwoofer Slope -12db/oct (A/B CH)	Frequency Response Channel 10Hz to 70kHz (+0dB,-3dB) A/B Ch
Frequency Response - Sub Channel 10Hz to 70kHz (+0dB,-3dB)	Fuse Rating 30 A x 1
Maximum Power Output 80 W x 4-Channel (4 Ohm), 130 W x 4-Channel (2 Ohm), 520 W (4 Ohm Bridged)	RCA Inputs 4-Channel
Signal to Noise 78 dBA (Reference: 1 W into 4 ohm)	Speaker Line input Sensor Yes

PRODUCT PERFORMANCE
Allowable Load Impedance 2 ohm to 8 ohm allowable
Avg Current Consumption (amps x #ch) 5.5 A x 4-Channel - 4 Ohm, 8.5 A x 2-Channel - 4 Ohm
Continuous-Power-Output 40 W x 4-Channel - 4 Ohm, 65 W x 4-Channel - 2 Ohm, 130 W x 2-Channel - 4 Ohm Bridged
Crossover Network Channel LPF - A/B Ch - 80 Hz, HPF - A Ch - 40 Hz to 500Hz, HPF - B Ch - 80Hz
Crossover Network Channel Slope -12db/oct (A/B CH)
Crossover Network Subwoofer Channel LPF - 80 Hz
Crossover Network Subwoofer Slope -12db/oct (A/B CH)
Frequency Response Channel 10Hz to 70kHz (+0dB,-3dB) A/B Ch
Frequency Response - Sub Channel 10Hz to 70kHz (+0dB,-3dB)
Fuse Rating 30 A x 1
Maximum Power Output 80 W x 4-Channel (4 Ohm), 130 W x 4-Channel (2 Ohm), 520 W (4 Ohm Bridged)
RCA Inputs 4-Channel
Signal to Noise 78 dBA (Reference: 1 W into 4 ohm)
Speaker Line input Sensor Yes

GM-A4704 - What's in the Box

Owner's Manual ()
Product Warranty ()

GM-A4704

$120.00
