Overview
The Pioneer Reference for Open Show series of speakers are designed specifically for those looking to produce serious sound pressure levels. Inspired by Pioneer’s history of record-breaking SPL competition, the new P.R.O. Series line of speakers is constructed with the street enthusiast in mind. With an emphasis on efficiency and power handling, the P.R.O. series lineup consists of bullet tweeters, mid bass drivers, and a subwoofer that can be mixed and matched to deliver impressive output, without requiring an impressive investment. The TS-B401PRO 4" High Efficiency Bullet Tweeter features 600 W Max Power (300 W Nominal) handling, a titanium diaphragm, and an aluminum die-cast chassis designed for high sensitivity and high power handling. TS-B401PRO sold individually (each, not a pair).

TS-B401PRO

Sale price $40.50
Regular price $50.00
Sold out

Find out if this product fits your vehicle

4" - 600 W Max Power, Titanium Diaphragm, High Efficiency Bullet Tweeter - PRO Series Component Speaker (sold individually)

600 W Max Power (300 W Nominal)

4" Titanium Diaphragm Bullet Tweeter (sold individually, not a pair)

Designed for High Sensitivity and High Power Handling

P.R.O. Series - Pioneer Reference for Open Show car audio systems

The Pioneer Reference for Open Show series of speakers are designed specifically for those looking to produce serious sound pressure levels. Inspired by Pioneer’s history of record-breaking SPL competition, the new P.R.O. Series line of speakers is constructed with the street enthusiast in mind. With an emphasis on efficiency and power handling, the P.R.O. series lineup consists of bullet tweeters, mid bass drivers, and a subwoofer that can be mixed and matched to deliver impressive output, without requiring an impressive investment. The TS-B401PRO 4" High Efficiency Bullet Tweeter features 600 W Max Power (300 W Nominal) handling, a titanium diaphragm, and an aluminum die-cast chassis designed for high sensitivity and high power handling. TS-B401PRO sold individually (each, not a pair).
FEATURES
Cut Out dimensions
3-3/4
Mounting Depth
2-5/8
Outer Diameter
4-5/8
Speaker Grill
NA
Tweeter
116mm
FEATURES
Cut Out dimensions
3-3/4
Mounting Depth
2-5/8
Outer Diameter
4-5/8
Speaker Grill
NA
Tweeter
116mm
MATERIALS
Cone Material
NA
Magnet Weight
431 g,15.2 oz
Magnet Material
Ferrite
MATERIALS
Cone Material
NA
Magnet Weight
431 g,15.2 oz
Magnet Material
Ferrite
PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts
300W
Crossover Frequency
2500 Hz
Frequency Response
2,500 Hz to 22 kHz
Maximum Peak Power Handling - Watts
600W
Nominal Impedance - Ohm
4-Ohm
Sensitivity (1W/1m)
106 dB
System-Type
Bullet Tweeter
PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts
300W
Crossover Frequency
2500 Hz
Frequency Response
2,500 Hz to 22 kHz
Maximum Peak Power Handling - Watts
600W
Nominal Impedance - Ohm
4-Ohm
Sensitivity (1W/1m)
106 dB
System-Type
Bullet Tweeter
Pioneer_TS-B401PRO_Front Image
TS-B401PRO
Sale price $40.50
Regular price $50.00
Sold out
