Name: TS-A120D4
Brand: Pioneer Electronics (USA) Inc.
SKU: TS-A120D4
Price: 120.0 USD
Availability: InStock

TS-A120D4

$120.00

Find out if this product fits your vehicle

Select quantity

12" - 1500 W Max Power, Dual 4 Ohm Voice Coil, IMPP™ cone, Rubber Surround - Component Subwoofer

1500 W Max Power (500 W Nominal)

Dual 4 Ohm Voice Coils

12” Glass Fiber and Mica Interlaced Injection Molded Polypropylene (IMPP) Cone Construction

Butyl rubber surround and polycotton / cotton dual spider for strength and linearity during high excursion

Oversized 60 oz double stacked magnet and vented pole yoke for increased power handling

Overview
Specs
Knowledgebase
Manuals/Warranty

12” Dual 4 Ω Voice Coil Subwoofer - Glass fiber and mica interlaced Injection Molded Polypropylene (IMPP™ cone construction, Butyl rubber surround and polycotton / cotton dual spider for strength and linearity during high excursion, Oversized 60 oz double stacked magnet and vented pole yoke for increased power handling.

A Series

The Pioneer A-Series speaker sound design purposely matches the subwoofer and full-range loudspeakers to provide seamless and smooth sound characteristics with dynamic, high-impact bass that lets you hear and feel the music. Pioneer’s OPEN & SMOOTH sound concept provides a seamless and smooth transition between the midrange and tweeter drivers and delivers uniform off-axis frequency response optimized for automotive applications where one or more speakers are often aimed away from the listeners’ ears. The A-Series lineup expands flexibility and improves acoustic performance. The integrated inline crossover network allows for increased installation flexibility without the need of an outboard module. Included with the Pioneer A-Series, are multi-fit installation adapters and tweeter mounts (when applicable).

Linear-Balanced Motion

Linear, balanced motion in both the forward and reverse directions of cone movement is critical in delivering accurate reproduction of recorded sound waves. Careful engineering of the entire motor structure and suspension system (voice coil, magnet, surround and spider) is required maintain a high level of linearity, even during high output / high excursion transients.

CarSoundfit

Pioneer’s Car Sound Fit app is actually a car sound simulator for experiencing in-car sound with your own smartphone. Hear the difference between original car speakers and different Pioneer audio upgrades: convince yourself of the level of quality Pioneer can offer for your vehicle. For a virtual listening demonstration of these and many other Pioneer car speakers, download the free Pioneer CarSoundFit app.

FEATURES
Amp - Grounding No	Built In Amp No
CarSoundFit Yes	Cut Out dimensions 11-1/8,28 cm
Equivalent Compliance (VAS) 87.1 Liters,3.1 Cu. Ft.	Free Air ResoNAnce (Fs) 25
Linear Excursion (Xmax) 10.1 mm,0.4	Mounting Depth 5-3/4,14.61cm
Port Diameter 3,8 cm	Port Length 6-1/2,17 cm
Recommended Ported Box Internal volume 42.5 Liters,1.5 Cu. Ft	Recommended Sealed Enclosure Volume 35.4 Liters,1.25 Cu Ft
Total Speaker Q (Qts) 0.69

FEATURES
Amp - Grounding No
Built In Amp No
CarSoundFit Yes
Cut Out dimensions 11-1/8,28 cm
Equivalent Compliance (VAS) 87.1 Liters,3.1 Cu. Ft.
Free Air ResoNAnce (Fs) 25
Linear Excursion (Xmax) 10.1 mm,0.4
Mounting Depth 5-3/4,14.61cm
Port Diameter 3,8 cm
Port Length 6-1/2,17 cm
Recommended Ported Box Internal volume 42.5 Liters,1.5 Cu. Ft
Recommended Sealed Enclosure Volume 35.4 Liters,1.25 Cu Ft
Total Speaker Q (Qts) 0.69

MATERIALS
Basket Material Metal	Center Cap Material ABS
Cone Material Carbon and Mica reinforced Injected Molded Polypropylene - IMPP	Custom Fit Basket No
Damper Poly cotton	Drive Cone Material No
Installation Ring ABS	Magnet Material Ferrite
Magnet Weight 60 oz	Surround Material Rubber
Surround Type Rolled	Voice Coil Material Kapton
Voice Coil Special Feature No	Voice Coil Type Dual Voice Coil 4-ohm
Voice Coil wire Copper	Wire Terminals Push Type

MATERIALS
Basket Material Metal
Center Cap Material ABS
Cone Material Carbon and Mica reinforced Injected Molded Polypropylene - IMPP
Custom Fit Basket No
Damper Poly cotton
Drive Cone Material No
Installation Ring ABS
Magnet Material Ferrite
Magnet Weight 60 oz
Surround Material Rubber
Surround Type Rolled
Voice Coil Material Kapton
Voice Coil Special Feature No
Voice Coil Type Dual Voice Coil 4-ohm
Voice Coil wire Copper
Wire Terminals Push Type

PRODUCT PERFORMANCE
Amp - Power Source No	Bass Boost No
Continuous Power handling (RMS) - Watts 500	Frequency Response 20 Hz to 2.3 kHz
Maximum Peak Power Handling - Watts 1500	Nominal Impedance - Ohm 4-Ohm dual
Sensitivity (1W/1m) 77 dB	Speaker Line input Sensor No
System-Type Component

PRODUCT PERFORMANCE
Amp - Power Source No
Bass Boost No
Continuous Power handling (RMS) - Watts 500
Frequency Response 20 Hz to 2.3 kHz
Maximum Peak Power Handling - Watts 1500
Nominal Impedance - Ohm 4-Ohm dual
Sensitivity (1W/1m) 77 dB
Speaker Line input Sensor No
System-Type Component

Pioneer TS-A120D4 - CarSoundFit App Listening Demonstration

TS-A120D4

$120.00
