Name: TS-Z10LS4
Brand: Pioneer Electronics (USA) Inc.
SKU: TS-Z10LS4
Price: 250.0 USD
Availability: InStock

TS-Z10LS4

$250.00

Find out if this product fits your vehicle

Select quantity

10" - 1300 W Max Power, Single 4 Ohm Voice Coil, Twaron Aramid Fiber + Cellulose Fiber Cone, Hi-Res Audio Certified Subwoofer optimized for small spaces

1300 Watts Max. Power / 400 Watts Nominal Power

10" Twaron® Aramid Fiber + Cellulose Fiber Dual Layer Cone

Butyl Rubber Surround & Dual Poly-Cotton spider

Frequency range: 20 Hz to 3.8 kHz

Speaker Impedance: 4 ohms

Speaker Efficiency: 76 dB (1W/1M)

Mounting depth: 3.2” (81mm)

Recommended Box volume : 0.6cu.ft. (sealed)

Overview
Specs
Knowledgebase
Manuals/Warranty

The Z-Series is designed for high fidelity, high output, and ease of installation. The TS-Z10LS4 10" subwoofer will handle up to 400 W RMS. The shallow basket design allows installation in places where an ordinary subwoofer will not fit. The oversized dual-layer cone of Twaron aramid fiber and cellulose fiber supported by a tough butyl rubber surround delivers accurate, hard-hitting bass notes even when the music is turned up loud. The lightweight die-cast aluminum basket provides an incredibly stable housing for the subwoofer, without any coloration. Its 4-Ω voice coil makes it a great match for most amplifiers.

Hear More

The Z-Series is based on highly advanced technology developed by Pioneer, utilizing carefully selected materials and parts, and benefiting from our decades of automotive loudspeaker design theory and testing expertise. Following Pioneer’s OPEN & SMOOTH™ sound concept, the Z-Series automotive loudspeakers feature smooth off-axis frequency response, superior directivity, and an extended frequency range, engineered specifically to produce dynamic, accurate sound quality for your car. The result is a purity of sound that achieves unprecedented audio artistry.

Shallow Compact Design

Subwoofers require an extremely strong basket to hold the cone, suspension, and motor structure together in perfect alignment, even during high excursions at low frequencies. Traditional subwoofers need large enclosures, which can be challenging to install seamlessly. The Z-Series subwoofer features a shallow 3.2" basket for installation flexibility, an oversized cone (15% larger compared to a conventional 10" subwoofer), and a motor structure with a powerful magnet. These elements combine to produce fast, detailed, and extended bass with tremendous impact and clarity.

As a final touch, Pioneer designed the subwoofer with a low Q value to achieve powerful and deep bass typically associated with larger subwoofers and enclosures, without sacrificing cabin space. These subwoofers are not only shallow but are also made for small enclosures!

Twaron® Aramid Fiber + Cellulose Fiber

Twaron® is a synthetic aramid fiber that is very strong, heat-resistant, and rigid when woven into a cloth material. Cellulose fibers are naturally self-damping and reduce unwanted resonance. This subwoofer's dual-layer cone, constructed with both a Twaron® layer and a cellulose layer, combines the strengths of both materials. The result is a fast response and clear bass, with low coloration and distortion.

Butyl Rubber Suspension

Made from a specially blended, highly durable, and moisture-resistant compound, the butyl rubber keeps the cone moving in a precise linear direction. Not only does it provide greater consistency across various excursions, but it also reduces unwanted vibration from the cone to the basket during signal changes and stops. This results in less distortion and superior bass frequency response.

High-Quality Dual-Spider Design

Pioneer's poly-cotton dual-spider design effectively supports the voice coil by damping cone vibrations and improving the linearity of sound reproduction. The softer part ensures smooth movement and clear sound even under high power, while the firmer part controls excessive vibrations and prevents unwanted movements that cause distortion.

The design of a slim subwoofer requires a smaller distance between the front and rear suspensions (spiders), reducing their effectiveness in maintaining the required linearity during low-frequency excursions. To counter this problem, Pioneer has developed a dual rear suspension design, increasing the precision of movement without increasing mechanical resistance. The goal is simple: to provide all the details of your music while offering excellent control during long excursions and maintaining a small footprint in your car.

Deep Bass

To achieve deep and tight bass, a rigid and lightweight cone is essential. However, without a proper motor structure, it’s useless if you’re looking for a good bass punch. This subwoofer uses a strontium magnet paired with a large copper voice coil and a glass-imide voice-coil former for better bass control under high excursions. This also helps achieve better heat dissipation.

CarSoundfit

Pioneer’s Car Sound Fit app is actually a car sound simulator for experiencing in-car sound with your own smartphone. Hear the difference between original car speakers and different Pioneer audio upgrades: convince yourself of the level of quality Pioneer can offer for your vehicle. For a virtual listening demonstration of these and many other Pioneer car speakers, download the free Pioneer CarSoundFit app.

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 400 W	Frequency Response 20 Hz to 3.8 kHz
Maximum Peak Power Handling - Watts 1300 W	Nominal Impedance - Ohm 4-Ohm
Sensitivity (1W/1m) 76dB	System-Type Component

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 400 W
Frequency Response 20 Hz to 3.8 kHz
Maximum Peak Power Handling - Watts 1300 W
Nominal Impedance - Ohm 4-Ohm
Sensitivity (1W/1m) 76dB
System-Type Component

FEATURES
CarSoundFit Yes	Cut Out dimensions 9-1/8",23.18 cm
Equivalent Compliance (VAS) 23.7 Liters,0.83 Cu. Ft.	Free Air ResoNAnce (Fs) 35
Linear Excursion (Xmax) 9.5 mm,3/8"	Mounting Depth 3-1/4"
Port Diameter 3",7.62 cm	Port Length 7-1/2",19.05 cm
Recommended Ported Box Internal volume 17 Liters,0.60 Cu. FT.	Recommended Sealed Enclosure Volume 0.6 Cu Ft,17 Liters
Total Speaker "Q" (Qts) 0.52

FEATURES
CarSoundFit Yes
Cut Out dimensions 9-1/8",23.18 cm
Equivalent Compliance (VAS) 23.7 Liters,0.83 Cu. Ft.
Free Air ResoNAnce (Fs) 35
Linear Excursion (Xmax) 9.5 mm,3/8"
Mounting Depth 3-1/4"
Port Diameter 3",7.62 cm
Port Length 7-1/2",19.05 cm
Recommended Ported Box Internal volume 17 Liters,0.60 Cu. FT.
Recommended Sealed Enclosure Volume 0.6 Cu Ft,17 Liters
Total Speaker "Q" (Qts) 0.52

MATERIALS
Basket Material Die Cast Aluminum	Cone Material IMPP - Composite
Damper Poly cotton	Drive Cone Material Twaron Aramid Fiber
Gasket Rubber	Installation Ring Polypropylene
Magnet Material Ferrite	Magnet Weight 70.2 oz
Surround Material Rubber	Surround Type Rolled
Voice Coil Bobbin Glass imide	Voice Coil Type Single Voice Coil
Voice Coil wire Copper	Wire Terminals Push Type

MATERIALS
Basket Material Die Cast Aluminum
Cone Material IMPP - Composite
Damper Poly cotton
Drive Cone Material Twaron Aramid Fiber
Gasket Rubber
Installation Ring Polypropylene
Magnet Material Ferrite
Magnet Weight 70.2 oz
Surround Material Rubber
Surround Type Rolled
Voice Coil Bobbin Glass imide
Voice Coil Type Single Voice Coil
Voice Coil wire Copper
Wire Terminals Push Type

Pioneer TS-Z10LS4 - Z Series 10 inch Subwoofer Overview
