Name: TS-A6961F
Brand: Pioneer Electronics (USA) Inc.
SKU: TS-A6961F
Price: 90.0 USD
Availability: InStock

TS-A6961F

$90.00

Find out if this product fits your vehicle

Select quantity

6" x 9" - 4-way, 450 W Max Power, Carbon/Mica-reinforced IMPP™ cone, 18mm Tweeter and 11mm Super Tweeter and 2-1/4" Cone Midrange - Coaxial Speakers (pair)

450 W Max Power (90 W Nominal)

18mm and 11mm Polyethylene Terephthalate (PET) hard dome tweeters

2-1/4" cellulose fiber cone midrange

6" x 9" Carbon and Mica reinforced Injection Molded Polypropylene (IMPP) cone construction

Overview
Specs
Knowledgebase
Manuals/Warranty

6" x 9" 4-way Coaxial Speaker - 450 W Max Power (90 W Nominal) 18mm and 11mm Super polyethylene terephthalate (PET) hard dome tweeter - 2-1/4" cellulose fiber cone midrange.

FEATURES
CarSoundFit Yes	Cut Out dimensions 8-3/4 x 6
Midrange 2-1/4,57.7 mm	Mounting Depth 2-7/8/72.9mm
Speaker Grill Included	Tweeter 18mm,11mm Super

FEATURES
CarSoundFit Yes
Cut Out dimensions 8-3/4 x 6
Midrange 2-1/4,57.7 mm
Mounting Depth 2-7/8/72.9mm
Speaker Grill Included
Tweeter 18mm,11mm Super

MATERIALS
Basket Material Metal	Cone Material Carbon and Mica reinforced Injected Molded Polypropylene - IMPP
Custom Fit Basket No	Damper Poly cotton Aramid
Diaphragm Material Cellulose fiber - Midrange	Magnet Material Ferrite - Woofer,Ferrite - Midrange
Magnet Weight 11.4 oz - Woofer,1.4 oz - Midrange	Surround Material Elastic Polymer
Surround Type Rolled	Voice Coil Material Glass Imide
Voice Coil wire Copper	Wire Terminals Lug Type

MATERIALS
Basket Material Metal
Cone Material Carbon and Mica reinforced Injected Molded Polypropylene - IMPP
Custom Fit Basket No
Damper Poly cotton Aramid
Diaphragm Material Cellulose fiber - Midrange
Magnet Material Ferrite - Woofer,Ferrite - Midrange
Magnet Weight 11.4 oz - Woofer,1.4 oz - Midrange
Surround Material Elastic Polymer
Surround Type Rolled
Voice Coil Material Glass Imide
Voice Coil wire Copper
Wire Terminals Lug Type

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 90	Crossover Frequency 4100 Hz (Acoustic), 3700 Hz (Electric)
Frequency Response 29 Hz to 28 kHz	Maximum Peak Power Handling - Watts 450
Nominal Impedance - Ohm 4-Ohm	Sensitivity (1W/1m) 92 dB
System-Type Coaxial 4-way

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 90
Crossover Frequency 4100 Hz (Acoustic), 3700 Hz (Electric)
Frequency Response 29 Hz to 28 kHz
Maximum Peak Power Handling - Watts 450
Nominal Impedance - Ohm 4-Ohm
Sensitivity (1W/1m) 92 dB
System-Type Coaxial 4-way

Meet the new A-Series line of speakers from Pioneer

Instruction Manual ()
Product Warranty ()

TS-A6961F

$90.00

Car Fit Guide Provided by

Guide provided for reference but cannot be guaranteed.
