TS-501M

Name: TS-501M
Brand: Pioneer Electronics (USA) Inc.
SKU: TS-501M
Price: 48.0 USD
Availability: OutOfStock

5.25" - 4-way 300 W Max Power, 11mm Tweeter and 11mm Super Tweeter and 1.63" Cone Midrange - Coaxial Speakers (pair)

$48.00

Orders of $100 or more will receive FREE shipping!

Does it fit your car?

Features

300W max power / 50W RMS per speaker

11mm Tweeter and 11mm Super Tweeter

1-5/8" cellulose fiber cone midrange

5-1/4" carbon and mica reinforced Injection Molded Polypropylene (IMPP) cone construction

Protective mesh grille included

Light weight elastic polymer surround

Heat resistant voice coil

Box contains 2 speakers

TS-501M

$48.00

Overview
Specs
Knowledgebase
Manuals/Warranty

Features You'll Love.

The TS-501M speaker offers a powerful audio experience with a maximum output of 300W and 50W RMS per speaker. It features an 11mm tweeter and super tweeter for clear high frequencies, and a 1-5/8" cellulose fiber cone midrange for rich mid-tones. The 5-1/4" carbon and mica reinforced Injection Molded Polypropylene (IMPP) cone ensures durability and excellent sound quality. The included protective mesh grille adds a layer of protection and style, while the lightweight elastic polymer surround and heat-resistant voice coil enhance reliability. The box contains two speakers, providing a complete audio solution.

A Series

The highly efficient design of the Pioneer A Series speakers intentionally matches the subwoofer and full-range loudspeakers to provide seamless and smooth sound characteristics, with dynamic, high-impact bass that lets you hear and feel the music. Pioneer's OPEN & SMOOTH sound concept ensures a seamless transition between the midrange and tweeter drivers, delivering a uniform off-axis frequency response optimized for automotive applications, where one or more speakers are often aimed away from the listeners' ears. The A Series lineup enhances audio details and improves acoustic performance.

Open & smooth

Pioneer’s OPEN & SMOOTH sound concept ensures a seamless and smooth transition between the midrange and tweeter drivers, delivering a uniform off-axis frequency response. This design is optimized for automotive applications where one or more speakers are often aimed away from the listeners’ ears.

PRODUCT PERFORMANCE
Continuous Power Handling (Rms) - Watts 50	Frequency Response 44 Hz to 52 kHz
Maximum Peak Power Handling - Watts 300	Nominal Impedance - Ohm 4-Ohm
Sensitivity (1W/1M) 89dB (+- 1.5dB)	System-Type 4-way coaxial, Twin Polyethylene terephthalate (PET) dome - Tweeter

PRODUCT PERFORMANCE
Continuous Power Handling (Rms) - Watts 50
Frequency Response 44 Hz to 52 kHz
Maximum Peak Power Handling - Watts 300
Nominal Impedance - Ohm 4-Ohm
Sensitivity (1W/1M) 89dB (+- 1.5dB)
System-Type 4-way coaxial, Twin Polyethylene terephthalate (PET) dome - Tweeter

FEATURES
Tweeter Dimensions 0.43", 0.43" Super	Woofer Dimensions 5.25"

FEATURES
Tweeter Dimensions 0.43", 0.43" Super
Woofer Dimensions 5.25"

MATERIALS
Basket Material Iron Plate Press	Cone Material IMPP - Composite
Cone Material-Midrange Cellulose fiber	Magnet Material Ferrite
Magnet Weight 7.41 oz	Surround Material Elastic Polymer
Voice Coil Bobbin Glass imide	Voice Coil wire Copper

MATERIALS
Basket Material Iron Plate Press
Cone Material IMPP - Composite
Cone Material-Midrange Cellulose fiber
Magnet Material Ferrite
Magnet Weight 7.41 oz
Surround Material Elastic Polymer
Voice Coil Bobbin Glass imide
Voice Coil wire Copper
