Name: TS-A6991F
Brand: Pioneer Electronics (USA) Inc.
SKU: TS-A6991F
Price: 130.0 USD
Availability: InStock

TS-A6991F

$130.00

Find out if this product fits your vehicle

Select quantity

6”x9" - 5-way, 700 W Max Power, Carbon/Mica-reinforced IMPP™ cone, 2-1/4" (57mm) PEI Cone Midrange, 18mm Tweeter and 11mm/9mm Super Tweeters - Coaxial Speakers (pair)

700 Watts Max. Power / 120 Watts Nominal Power

6”x9" Carbon and Mica reinforced IMPP™ cone

2-1/4" (57mm) polyetherimide (PEI) cone midrange

18mm PET hard dome Tweeter

11mm & 9mm PET hard dome Super Tweeters

Frequency range: 29 Hz to 33 kHz

Speaker Impedance: 4 ohms

Speaker Efficiency: 92 dB (1W/1M)

Overview
Specs
Knowledgebase
Manuals/Warranty

6" x 9" 5-way Coaxial Speaker - 700 W Max Power (120 W Nominal) 18mm, 11mm Super and 9mm Super polyethylene terephthalate (PET) hard dome tweeters - 2-1/4" polyetherimide (PEI) film cone midrange.

A Series

The highly efficient design of the Pioneer A Series speakers intentionally matches the subwoofer and full-range loudspeakers to provide seamless and smooth sound characteristics, with dynamic, high-impact bass that lets you hear and feel the music. Pioneer's OPEN & SMOOTH sound concept ensures a seamless transition between the midrange and tweeter drivers, delivering a uniform off-axis frequency response optimized for automotive applications, where one or more speakers are often aimed away from the listeners' ears. The A Series lineup enhances audio details and improves acoustic performance.

Loud & Clear

These speakers are designed with a dual-port bass-reflex system to provide not only more bass but also a cleaner bass output than typical speakers of the same size. They allow you to enjoy coherent sound without missing any details and without exaggerated response, offering improved precision and more detail across the entire audio bandwidth. Their efficiency also enables you to enjoy exceptional sound from low-power sources, while their ability to handle high-power head units or small amplifiers ensures versatility.

Open & smooth

Pioneer’s OPEN & SMOOTH sound concept ensures a seamless and smooth transition between the midrange and tweeter drivers, delivering a uniform off-axis frequency response. This design is optimized for automotive applications where one or more speakers are often aimed away from the listeners’ ears.

Carbon and Mica reinforced IMPP™ cone

An extremely rigid yet lightweight cone is essential to avoid cone failure and distortion under high power. Pioneer’s IMPP™ composite cones meet this need perfectly. CAE (Computer-Aided Engineering) was applied to create a curvilinear cone with varying thicknesses during the injection process, maintaining a balance between lightness (responsiveness) and rigidity (precise audio and tight bass). To further improve this rigidity-to-weight ratio, Pioneer uses an advanced process that integrates different materials, such as carbon and mica, which resonate at different frequencies, creating a perfectly balanced cone across the entire bandwidth.

Polyetherimide (PEI) midrange with (PET) hard dome tweeters

PEI and PET materials can withstand high temperatures while maintaining stable electrical and mechanical properties over a wide frequency range. Their strength-to-weight ratio makes them ideal for high-frequency vibrations of the dome and thermal management of the voice coil. We also carefully designed these components with a front diffuser to help maintain the perfect audio balance during the transition from on-axis to off-axis listening. This allows for a more balanced sound source between the different audio points in the car.

Keep it simple and clean

Avoid messy installations and keep your speaker wiring as clean as possible. These speakers use an in-line crossover design and/or an integrated crossover already installed on the speaker basket. This eliminates the need for a bulky external box typically found with passive crossovers, saving you from having to find extra space for it. Additionally, it removes the need for extra wires going in and out of your door to accommodate a woofer in the door with a matching tweeter on your dash.

CarSoundfit App

Pioneer's Car Sound Fit app is a car sound simulator that lets you experience what your car could sound like using your own smartphone. You'll be able to hear the difference between stock speakers and Pioneer's various audio options, and see how the quality of Pioneer speakers can enhance your in-car experience. For a virtual listening demo of these and many other Pioneer car speakers, download the free Pioneer CarSoundFit app.

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 120	Crossover Frequency 2700 Hz (Acoustic),3500 Hz (Electric)
Frequency Response 29 Hz to 33 kHz	Maximum Peak Power Handling - Watts 700
Nominal Impedance - Ohm 4-Ohm	Sensitivity (1W/1m) 92 dB
System-Type Coaxial 5-way,Triple Polyethylene terephthalate (PET) dome - Tweeter

PRODUCT PERFORMANCE
Continuous Power handling (RMS) - Watts 120
Crossover Frequency 2700 Hz (Acoustic),3500 Hz (Electric)
Frequency Response 29 Hz to 33 kHz
Maximum Peak Power Handling - Watts 700
Nominal Impedance - Ohm 4-Ohm
Sensitivity (1W/1m) 92 dB
System-Type Coaxial 5-way,Triple Polyethylene terephthalate (PET) dome - Tweeter

FEATURES
Cut Out dimensions 8-3/4 x 6	Midrange 2-1/4
Mounting Depth 3-3/8/85.7mm	Tweeter 18mm,11mm Super,9mm Super

FEATURES
Cut Out dimensions 8-3/4 x 6
Midrange 2-1/4
Mounting Depth 3-3/8/85.7mm
Tweeter 18mm,11mm Super,9mm Super

MATERIALS
Basket Material Iron Plate Press	Cone Material Carbon and Mica reinforced Injected Molded Polypropylene - IMPP
Damper Poly cotton Aramid	Diaphragm Material Polyetherimide (PEI) - Midrange
Magnet Material Ferrite - Woofer,Ferrite - Tweeter	Magnet Weight 29.6 oz - Woofer,1.4 oz - Tweeter
Surround Material Elastic Polymer	Surround Type Rolled
Voice Coil Bobbin Glass Imide	Voice Coil Material Glass Imide
Voice Coil wire Copper	Wire Terminals Lug Type

MATERIALS
Basket Material Iron Plate Press
Cone Material Carbon and Mica reinforced Injected Molded Polypropylene - IMPP
Damper Poly cotton Aramid
Diaphragm Material Polyetherimide (PEI) - Midrange
Magnet Material Ferrite - Woofer,Ferrite - Tweeter
Magnet Weight 29.6 oz - Woofer,1.4 oz - Tweeter
Surround Material Elastic Polymer
Surround Type Rolled
Voice Coil Bobbin Glass Imide
Voice Coil Material Glass Imide
Voice Coil wire Copper
Wire Terminals Lug Type

Meet the new A-Series line of speakers from Pioneer

Instruction Manual ()
Product Warranty ()

TS-A6991F

$130.00

Car Fit Guide Provided by

Guide provided for reference but cannot be guaranteed.
